| Application |
Asset Tracking, Barcode Labeling, Circuit Board Labeling, General Identification |
| Shipped With Battery |
Yes |
| How Is Battery Shipped |
Shipped in box, not installed |
| Battery Weight |
0.14 lb |
| Connectivity Options |
Bluetooth® 5 Low Energy (class II) |
| Device Drop Test & Durability |
Resistant to 250-lb crushes, Resistant to 6-foot drops, Resistant to military-grade shocks (MIL-STD-810G) |
| Plug Type |
US |
| Power Supply Voltage |
100 - 240 V @ 50 - 60 Hz |
| Scanner Model |
V4500 |
| Portability |
Portable |
| Wireless or Wired |
Wireless |
| Battery Type |
Rechargeable Lithium-ion Battery |
| Rotational Tolerance |
± 180° |
| Sensor |
CMOS 1.2 Megapixel |
| Field of View |
High Density Field: 30° Horizontal by 20° Vertical, Wide Field: 50° Horizontal by 33.5° Vertical |
| Focal Point |
Approximately 100 mm |
| Power Requirements |
10W |
| Number of Scans |
Up to 75,000 scans per charge |
| Optical Resolution |
High Density Field: 960 x 640, Wide Field: 960 x 640 |
| Pitch |
± 65° (from front to back) |
| Skew |
± 60° from plane parallel to symbol (side-to-side) |
| Target Beam |
Single blue targeting bar |
| Image Output Options |
JPEG, PGM |
| 1D / 2D Barcode Capability |
2D |
| Decode Capability - 1D |
BC412, Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, GS1 DataBar, Hong Kong 2 of 5, IATA 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Pharmacode, Plessey, Straight 2 of 5, Telepen, Trioptic, UPC / EAN / JAN |
| Decode Capability - 1D Stacked |
Codablock F, Code 49, GS1 Composite (CC-A/CC-B/CC-C), MicroPDF, PDF417 |
| Decode Capability - 2D |
Aztec Code, Data Matrix, Data Matrix Rectangular Ext'n, GoCode® (proprietary--add'l license req'd), Grid Matrix, HanXin Code, Micro QR Code, QR Code, QR Model 1 |
| Decode Capability - Postal |
Australian Post, Canada Post, Intelligent Mail, Japan Post, KIX Code, Korea Post, Planet, Post-Net, UK Royal Mail, UPU ID-tags |
| Field Selection |
High Density or Wide Field |
| Advanced Data Editing |
JavaScript |
| Symbol Contrast |
15% minimum reflectance difference |
| Ambient Light Immunity |
Sunlight: Up to 9,000ft-candles/96,890 lux |
| Charging Station w/BT Radio Communication Interfaces |
RS232, USB 2.0 (generic HID, HID keyboard, virtual com port) |
| Reader/Scanner Unit Communication |
Bluetooth 5 Low Energy (class II) |
| Data Parsing |
Driver's licenses and ID Cards (optional license required), GS1, HIBC |
| Data Structure Validation |
HIBC UDI, ISO 15418, ISO 15434 |
